USB-C DUAL DAC CABLE
- CS43198
Dual DAC - 32bit 384kHz
bit to bit play - Native DSD
- On/Off
LED Indicator - Full Metal Body
- Shielded silver
Plated Copper Cable - Powerful
Output Level
SMALL, BUT MIGHTY
Full Metal Housing Design
Dual-DAC HiFi Audio Chipset
Silver-Plated Copper Shielded Cable
Small Size, but Powerful Output
The Astell&Kern USB-C DUAL DAC CABLE has been designed as an extension of existing Astell&Kern DAP
lines.
Smartphone manufacturers are removing headphone jacks from their products.
Without a
headphone jack, how do you listen to music on your smartphone with the headphones and earphones you
currently own?
As streaming services begin to support high-quality, high-resolution audio, are wireless earphones and
headphones able to provide
the full audio playback experience?
How can you enjoy high-quality music playback or games with dynamic and realistic sound on your computer
without an expensive high-end sound card?
Our development team set out to create a product that would answer these questions.
Dedicated Dual DAC with Hi-Fi,
Ultra High Resolution Sound
The Astell&Kern USB-C DUAL DAC Cable features two Cirrus Logic CS43198 MasterHIFI™ DACs which supports native DSD256 and 32bit/384kHz playback.
With the USB-C DUAL DAC Cable, you can experience premium, high-resolution audio from your computer or mobile device.
Small But Powerful Output,
Astell&Kern’s Signature Sound and Design
Astell&Kern’s expertise in audio circuit design has allowed us to create a complex and highly
integrated circuit chip on a small,
six-layer PCB the size of 14 x 41 mm.
In order to create a small device, micro resistors and tantalum capacitors, exclusively created for
Astell&Kern were used.
These same capacitors, which are used by AK DAPs, optimize the audio circuit to suppress power
fluctuations, creating a USB DAC that provides stable operation and superb audio performance.
The dual CS43198 DACs are paired with an independent analog amplifier, designed to provide true audio
playback so you can feel the live,
warm and clear sound as intended, without distortion. This is possible based on years of Astell&Kern’s
expertise in AMP design.
Although it is a small and simple cable type external DAC,
it is able to sufficiently drive high impedance headphones with a 2Vrms (Condition No Load) output
level.
Plug & Play with Most Devices
The Astell&Kern USB-C DUAL DAC Cable features a USB-C connection, which can be found on the latest Android-based smartphones and Windows and Mac computers.
Since the USB-C DUAL DAC Cable draws power from the playback device it is connected to, there is no need for a separate charger. The USB-C DUAL DAC Cable supports any headphone or earphone with a 3.5mm connector.
The USB-C DUAL DAC Cable brings the famous signature Astell&Kern sound to your devices for a reasonable price.
- Both earphones and headphones that support 3-pole and 4-pole 3.5mm plugs can be used, but the in-line controller and microphone functions built into 4-pole earphones and headphones are not supported.
Noise-Shielded Customized Cable
We developed a custom-made, 4-core cable to express the sound you want to reveal through the cable and
enhance durability against disconnection.
The cable is reinforced to withstand up to
200N of tensile force using aramid fiber.
This cable is made by wrapping silver-plated copper wire and the copper wire in a spiral form around a center core made of Technora Aramid fiber to block external noise.
A separate shielding treatment is applied to the cable to block distortion and noise of digital and analog signals from the playback device.
The silver-plated copper wire used in the USB-C DUAL DAC Cable is thicker than typical silver-plated
copper wire (0.3μm, usually 0.1~0.15µm).
The addition of copper wire provides clear and rich spatial sound.
Non Migration TPE
Spiral Shielding_Copper
Technora Aramid fiber
0.5mm copper
0.3μm silver-plating
Design Concept
The USB-C DUAL DAC Cable uses the design concept of “light and
shadow” that is used in
all Astell&Kern products. The USB-C DUAL DAC
Cable design is based on a single
centerline that boldly crosses from
right to left. The faces were arranged by
adjusting the angle ratio so that
the sharp faces of the upper four faces meet at one
point. It is designed
so that each side is reflected according to the movement of
light.
To make the grip comfortable for one-handed use, the surface was
created to be like a
pebble that has been smoothly polished by the
natural weathering effect of stone,
rather than featuring the sharper
angles typically found in existing AK products.
This product design
provides a nice, smooth feeling when holding the cable in your
hand.
The weight of the metal material used reflects the same durability and
solid feel
compared to other Astell&Kern devices.
Precautions When Using the Product
The Astell&Kern USB-C DUAL DAC Cable is compatible with most Android-based smartphones and tablet
PCs,
computers running Windows 10 and macOS.
iOS-based devices, such as iPhones and iPads are currently not supported.
Some Android devices may require adjusting certain settings to function correctly.
to hardware, software, and system limitations of certain supported devices, not all functions may work correctly or be available for use.
When connected to a Windows PC, the device is automatically recognized and the correct driver will be
installed. A separate USB DAC Driver installation may be required for high-quality sound playback, and
can be downloaded
from the Support-Download section of the Astell&Kern global website.
To play DSD and high-quality PCM sound sources on a smartphone, a separate free/paid app that supports high-resolution audio playback must be installed. (When using the smartphone's own built-in player, audio may be down-sampled)
When connecting to a playback device (Android-based smartphone, tablet PC, and PC), be sure to check the
volume level before connecting earphones and headphones. Some devices may automatically set the output
level to maximum volume when the USB-C DUAL DAC Cable is connected.
Listening to headphones or earphones
at maximum volume may damage your hearing. Please verify the volume level before each use.
When connecting the USB-C DUAL DAC Cable to an Astell&Kern player and using the cable as an external DAC, the output volume will be fixed at the maximum volume setting. It is not possible to adjust the volume through the Astell&Kern player. Listening at maximum or a high volume setting may cause serious damage to your hearing. Astell&Kern, its affiliates and agencies, cannot be held liable for any damage or injuries from negligent or inappropriate use. We do not recommend using the USB-C DUAL DAC Cable with Astell&Kern players.
Firmware updates may be released periodically for stability improvements. For more information on firmware updates and to check if a firmware update is available, please visit the Support-Download section of the Astell&Kern global website.
